Sansui 771

AM/FM Stereo Receiver (1973-77)

Description

Thanks to its refined Circuit Board Module construction, the Sansui 771 outperforms many higher priced receivers in the field.

It offers a very superior power amplifier, an all-stage direct coupled OCL powerhouse delivering a continuous 40wpc to drive up to two pairs of speakers at a time.

The preamplifier section and control sections are equally outstanding, providing inputs and controls for two tape decks, two aux, a microphone circuit, a phono circuit and an FM multiplex circuit.

Specifications

Tuning range: FM, MW

Power output: 32 watts per channel into 8Ω (stereo)

Frequency response: 15Hz to 30kHz

Total harmonic distortion: 0.5%

Damping factor: 60

Input sensitivity: 2.5mV (mic), 2.5mV (MM), 100mV (DIN), 100mV (line)

Signal to noise ratio: 70dB (MM), 80dB (line)

Channel separation: 45dB (MM), 45dB (line)

Output: 100mV (line), 30mV (DIN)

Speaker load impedance: 4Ω to 16Ω

Semiconductors: 3 x FET, 3 x IC, 49 x transistors, 25 x diodes, 4 x zener diodes

Dimensions: 480 x 135 x 300mm

Weight: 12kg

Year: 1973
