MC X10 lays the foundation for high-fidelity sound. Its refined elliptical diamond stylus delivers clarity and precision, bringing your records to life with stunning detail. It’s the perfect starting point for an exceptional audio journey

Specifications
Channel balance at 1 kHz
0.5 dB
Output voltage at 1 kHz, 5cm/sec
0.4 mV
Channel separation at 1 kHz
24 dB
Frequency response 20 Hz - 20 kHz
+/-2 dB
Compliance, dynamic, lateral
13 μm/mN
Cantilever material
Aluminium
Stylus type
Elliptical
Stylus tip radius
r/R 8/18 μm
Stylus suspensions
Ortofon exclusive
Coil system
Quad coils
Tracking force, recommended
2.0 grams
Internal impedance, DC resistance
6 Ω
Coil wire material
High-purity silver
Cartridge weight
8.6 grams
Recommended load resistance
> 50 Ω
